| Code | Size | Stranding | Diameter of Wire | Diameter | Norminal Mass |
Rated Strength | |||||||||||
| Al | St | Al | St | GA2 or MA2 | GA3 or MA3 | GA4 or MA4 | GA5 or MA5 | AW2 | AW3 | ||||||||
| \ | kcmil | Nos | Nos | in. | in. | in. | lb/1000ft | kips | kips | kips | kips | kips | kips | ||||
| Partidge/ACSS | 266.8 | 26 | 7 | 0.1013 | 0.0788 | 0.6416 | 366.8 | 8.9 | 9.7 | 10.8 | 11.4 | 8.4 | 8.9 | ||||
| Junco/ACSS | 266.8 | 30 | 7 | 0.0943 | 0.0943 | 0.6601 | 417.4 | 11.7 | 13.0 | 14.4 | 15.2 | 11.2 | 11.7 | ||||
| Ostrich/ACSS | 300 | 26 | 7 | 0.1074 | 0.0835 | 0.6801 | 412.4 | 10.0 | 10.9 | 12.1 | 12.8 | 9.4 | 10.0 | ||||
| Linnet/ACSS | 336.4 | 26 | 7 | 0.1137 | 0.0885 | 0.7203 | 462.5 | 11.2 | 12.3 | 13.6 | 14.4 | 10.5 | 11.2 | ||||
| Oriole/ACSS | 336.4 | 30 | 7 | 0.1059 | 0.1059 | 0.7413 | 526.3 | 14.8 | 16.3 | 18.2 | 19.1 | 14.2 | 14.8 | ||||
| Brant/ACSS | 397.5 | 24 | 7 | 0.1287 | 0.0858 | 0.7722 | 511.4 | 11.0 | 12.1 | 13.3 | 14.4 | 10.4 | 11.0 | ||||
| Ibis/ACSS | 397.5 | 26 | 7 | 0.1236 | 0.0962 | 0.7830 | 546.5 | 13.0 | 14.2 | 15.8 | 163.5 | 12.4 | 13.0 | ||||
| Lark/ACSS | 397.5 | 30 | 7 | 0.1151 | 0.1151 | 0.8057 | 621.9 | 17.5 | 19.3 | 21.5 | 22.6 | 16.7 | 17.5 | ||||
| Flicker/ACSS | 477 | 24 | 7 | 0.1410 | 0.0940 | 0.8460 | 613.6 | 130. | 14.2 | 15.7 | 16.4 | 12.5 | 13.0 | ||||
| Hawk/ACSS | 477 | 26 | 7 | 0.1354 | 0.1053 | 0.8575 | 655.8 | 15.6 | 17.1 | 18.9 | 19.8 | 14.9 | 15.6 | ||||
| Hen/ACSS | 477 | 30 | 7 | 0.1261 | 0.1261 | 0.8827 | 746.3 | 21.0 | 22.7 | 25.3 | 26.7 | 20.1 | 20.5 | ||||
| Parakeet/ACSS | 556.5 | 24 | 7 | 0.1523 | 0.1015 | 0.9137 | 716.1 | 15.2 | 16.6 | 18.3 | 19.1 | 14.6 | 15.2 | ||||
| Dove/ACSS | 556.5 | 26 | 7 | 0.1463 | 0.1138 | 0.9266 | 765.1 | 18.2 | 19.9 | 22.1 | 23.1 | 17.5 | 18.2 | ||||
| Eagle/ACSS | 556.5 | 30 | 7 | 0.1362 | 0.1362 | 0.9534 | 870.6 | 24.5 | 26.5 | 29.6 | 31.1 | 22.9 | 24.0 | ||||
| Peacock/ACSS | 605 | 24 | 7 | 0.1588 | 0.1058 | 0.9526 | 778.3 | 16.5 | 18.0 | 19.9 | 20.8 | 15.9 | 16.5 | ||||
| Squab/ACSS | 605 | 26 | 7 | 0.1525 | 0.1186 | 0.9658 | 831.8 | 19.7 | 21.7 | 24.0 | 25.1 | 19.0 | 19.7 | ||||
| Wood Duck/ACSS | 605 | 30 | 7 | 0.1420 | 0.1420 | 0.9940 | 946.5 | 26.0 | 28.3 | 31.6 | 33.3 | 24.4 | 25.5 | ||||
| Teal/ACSS | 605 | 30 | 19 | 0.1420 | 0.0852 | 0.9940 | 938.6 | 26.6 | 29.3 | 32.6 | 34.7 | 25.0 | 26.6 | ||||
| Rook/ACSS | 636 | 24 | 7 | 0.1628 | 0.1085 | 0.9767 | 818.2 | 17.3 | 19.0 | 20.9 | 21.9 | 16.7 | 17.3 | ||||
| Grosbeak/ACSS | 636 | 26 | 7 | 0.1564 | 0.1216 | 0.9904 | 874.4 | 20.7 | 22.4 | 24.8 | 26.0 | 19.9 | 20.3 | ||||
| Scoter/ACSS | 636 | 30 | 7 | 0.1456 | 0.1456 | 1.0192 | 995.0 | 27.4 | 29.7 | 33.2 | 35.0 | 25.1 | 26.8 | ||||
| Egret/ACSS | 636 | 30 | 19 | 0.1456 | 0.0874 | 1.0194 | 986.8 | 28.0 | 30.9 | 34.3 | 36.6 | 26.3 | 28.0 | ||||
| Flamingo/ACSS | 666.6 | 24 | 7 | 0.1667 | 0.1111 | 1.0001 | 857.6 | 18.2 | 19.9 | 21.9 | 22.9 | 17.5 | 18.2 | ||||
| Gannet/ACSS | 666.6 | 26 | 7 | 0.1601 | 0.1245 | 1.0139 | 916.4 | 21.7 | 23.4 | 26.0 | 27.3 | 20.9 | 21.3 | ||||
| Stilt/ACSS | 715.5 | 24 | 7 | 0.1727 | 0.1151 | 1.0361 | 920.5 | 19.5 | 21.3 | 23.5 | 24.6 | 18.8 | 19.5 | ||||
| Starling/ACSS | 715.5 | 26 | 7 | 0.1659 | 0.1290 | 1.0506 | 983.7 | 23.3 | 25.2 | 27.9 | 29.3 | 22.0 | 22.9 | ||||
| Redwing/ACSS | 715.5 | 30 | 19 | 0.1544 | 0.0927 | 1.0811 | 1100.0 | 30.9 | 34.1 | 37.9 | 39.8 | 29.5 | 30.9 | ||||
| Cuckoo/ACSS | 795 | 24 | 7 | 0.1820 | 0.1213 | 1.0919 | 1023.0 | 21.7 | 23.3 | 25.7 | 26.9 | 20.9 | 21.3 | ||||
| Drake/ACSS | 795 | 26 | 7 | 0.1749 | 0.1360 | 1.1076 | 1093.0 | 25.9 | 28.0 | 31.0 | 32.6 | 24.4 | 25.4 | ||||
| Macaw/ACSS | 795 | 42 | 7 | 0.1376 | 0.0764 | 1.0548 | 857.5 | 11.8 | 12.6 | 13.6 | 14.2 | 11.4 | 11.8 | ||||
| Tern/ACSS | 795 | 45 | 7 | 0.1329 | 0.0886 | 1.0632 | 894.9 | 14.2 | 15.2 | 16.5 | 17.4 | 13.5 | 14.2 | ||||
| Condor/ACSS | 795 | 54 | 7 | 0.1213 | 0.1213 | 1.0917 | 1023.0 | 21.7 | 23.3 | 25.7 | 26.9 | 20.9 | 21.3 | ||||
| Mallard/ACSS | 795 | 30 | 19 | 0.1628 | 0.0977 | 1.4653 | 1233.0 | 34.3 | 37.9 | 42.1 | 44.3 | 32.9 | 34.3 | ||||
| Ruddy/ACSS | 900 | 45 | 7 | 0.1414 | 0.0943 | 1.1313 | 1013.0 | 15.8 | 17.0 | 18.5 | 19.2 | 15.3 | 15.8 | ||||
| Canary/ACSS | 900 | 54 | 7 | 0.1291 | 0.1291 | 1.1619 | 1158 | 24.6 | 26.4 | 29.1 | 30.5 | 23.2 | 24.1 | ||||
| Redbird/ACSS | 954 | 24 | 7 | 0.1994 | 0.1329 | 1.1963 | 1227 | 26.0 | 28.0 | 30.9 | 32.3 | 24.6 | 25.5 | ||||
| Rail/ACSS | 954 | 45 | 7 | 0.1456 | 0.0971 | 1.1649 | 1074 | 16.7 | 18.0 | 19.6 | 20.4 | 16.2 | 16.7 | ||||
| Towhee/ACSS | 954 | 48 | 7 | 0.1410 | 0.1097 | 1.1751 | 1122 | 19.7 | 21.3 | 23.3 | 24.3 | 19.0 | 19.7 | ||||
| Cardinal/ACSS | 954 | 54 | 7 | 0.1329 | 0.1329 | 1.1961 | 1227 | 26.0 | 28.0 | 30.9 | 32.3 | 24.6 | 25.5 | ||||
| Canvasback/ACSS | 954 | 30 | 19 | 0.1783 | 0.1070 | 1.2482 | 1480 | 41.1 | 45.4 | 50.5 | 53.1 | 39.4 | 41.1 | ||||
| Snowbird/ACSS | 1033.5 | 42 | 7 | 0.1569 | 0.0871 | 1.2027 | 1115 | 15.4 | 16.4 | 17.7 | 18.5 | 14.8 | 15.4 | ||||
| Ortolan/ACSS | 1033.5 | 45 | 7 | 0.1515 | 0.1010 | 1.2120 | 1163 | 18.1 | 19.5 | 21.2 | 22.0 | 17.6 | 18.1 | ||||
| Curlew/ACSS | 1033.5 | 54 | 7 | 0.1383 | 0.1383 | 1.2447 | 1330 | 28.2 | 30.3 | 33.4 | 35.0 | 26.1 | 27.7 | ||||
| Bluejay/ACSS | 1113 | 45 | 7 | 0.1573 | 0.1048 | 1.2582 | 1253 | 19.5 | 21.0 | 22.8 | 23.8 | 18.9 | 19.5 | ||||
| Finch/ACSS | 1113 | 54 | 19 | 0.1436 | 0.0861 | 1.2921 | 1429 | 30.4 | 33.2 | 36.5 | 38.7 | 28.7 | 30.4 | ||||
| Bunting/ACSS | 1192.5 | 45 | 7 | 0.1628 | 0.1085 | 1.3023 | 1342 | 20.9 | 22.5 | 24.5 | 25.4 | 20.3 | 20.9 | ||||
| Grackle/ACSS | 1192.5 | 54 | 19 | 0.1486 | 0.0892 | 1.3376 | 1531 | 32.6 | 35.5 | 39.1 | 41.5 | 30.8 | 32.6 | ||||
| Bittern/ACSS | 1272 | 45 | 7 | 0.1681 | 0.1121 | 1.3449 | 1432 | 22.3 | 24.0 | 26.1 | 27.1 | 21.6 | 22.3 | ||||
| Pheasant/ACSS | 1272 | 54 | 19 | 0.1535 | 0.0921 | 1.3815 | 1633 | 34.1 | 37.3 | 41.1 | 43.0 | 32.8 | 34.1 | ||||
| Dipper/ACSS | 1351 | 45 | 7 | 0.1733 | 0.1155 | 1.3863 | 1521 | 23.7 | 25.5 | 27.7 | 28.8 | 23.0 | 23.7 | ||||
| Martin/ACSS | 1351 | 54 | 19 | 0.1528 | 0.0949 | 1.3913 | 1735 | 36.2 | 39.6 | 43.6 | 45.6 | 34.9 | 36.2 | ||||
| Bobolink/ACSS | 1431 | 45 | 7 | 0.1783 | 0.1189 | 1.4265 | 1611 | 25.1 | 27.0 | 29.4 | 30.5 | 24.3 | 25.1 | ||||
| Plover/ACSS | 1431 | 54 | 19 | 0.1628 | 0.0977 | 1.4653 | 1837 | 38.4 | 41.9 | 46.2 | 48.3 | 36.9 | 38.4 | ||||
| Nuthatch/ACSS | 1510 | 45 | 7 | 0.1832 | 0.1221 | 1.4655 | 1700 | 26.5 | 28.1 | 30.6 | 31.8 | 25.7 | 26.1 | ||||
| Parrot/ACSS | 1510 | 54 | 19 | 0.1672 | 0.1003 | 1.5047 | 1939 | 40.4 | 44.2 | 48.7 | 51.0 | 38.9 | 40.4 | ||||
| Ratite/ACSS | 1590 | 42 | 7 | 0.1946 | 0.1080 | 1.4919 | 1715 | 23.4 | 25.0 | 26.9 | 27.9 | 22.7 | 23.4 | ||||
| Lapwing/ACSS | 1590 | 45 | 7 | 0.1880 | 0.1253 | 1.5039 | 1790 | 27.9 | 29.6 | 32.2 | 33.5 | 27.0 | 27.5 | ||||
| Falcon/ACSS | 1590 | 54 | 19 | 0.1716 | 0.1030 | 1.5446 | 2041 | 42.6 | 46.6 | 51.4 | 53.7 | 41.1 | 42.6 | ||||
| Chukar/ACSS | 1780 | 84 | 19 | 0.1456 | 0.0873 | 1.3101 | 2071 | 35.3 | 38.2 | 41.6 | 43.9 | 33.6 | 35.3 | ||||
| Mockingbird/ACSS | 2034.5 | 72 | 7 | 0.1681 | 0.1121 | 1.3449 | 2159 | 27.2 | 28.9 | 31.0 | 32.0 | 26.5 | 27.2 | ||||
| Roadrunner/ACSS | 2057 | 76 | 19 | 0.1645 | 0.0768 | 1.3710 | 2245 | 31.7 | 33.9 | 36.5 | 38.3 | 30.3 | 31.7 | ||||
| Bluebird/ACSS | 2156 | 84 | 19 | 0.1602 | 0.0961 | 1.4417 | 2508 | 42.1 | 45.5 | 49.6 | 51.7 | 40.7 | 42.1 | ||||
| Kiwi/ACSS | 2167 | 72 | 7 | 0.1735 | 0.1157 | 1.3881 | 2300 | 29.0 | 30.8 | 33.0 | 34.1 | 28.2 | 29.0 | ||||
| Thrasher/ACSS | 2312 | 76 | 19 | 0.1444 | 0.0814 | 1.4534 | 2524 | 35.6 | 38.1 | 41.0 | 43.0 | 34.1 | 35.6 | ||||
| Joree/ACSS | 2515 | 76 | 19 | 0.1819 | 0.0849 | 1.5159 | 2745 | 38.7 | 41.4 | 44.6 | 46.8 | 37.1 | 38.7 | ||||
