| Code | Area | Number of Wires | Wire Diameter | Diameter | Linear Mass | Rated Strength | Max. D.C. Resistance at 20℃ |
|||||
| Al | ACS | Total | Al | ACS | Al | ACS | ACS Core | Conductor | ||||
| \ | mm2 | mm2 | mm2 | Nos | Nos | mm | mm | mm | mm | kg/km | kN | Ω/km |
| 16 | 15 | 2.56 | 17.56 | 6 | 1 | 1.81 | 1.81 | 1.81 | 5.43 | 59 | 5.91 | 1.7923 |
| 25 | 24 | 4 | 28 | 6 | 1 | 2.26 | 2.26 | 2.26 | 6.78 | 92.1 | 9.0 | 1.1471 |
| 40 | 38 | 6.4 | 44.4 | 6 | 1 | 2.85 | 2.85 | 2.85 | 8.55 | 147.4 | 14.21 | 0.7169 |
| 63 | 60 | 10.08 | 70.08 | 6 | 1 | 3.58 | 3.58 | 63.58 | 10.7 | 232.2 | 21.17 | 0.4552 |
| 100 | 96 | 16 | 112 | 6 | 1 | 4.51 | 4.51 | 4.51 | 13.5 | 368.6 | 31.84 | 0.2868 |
| 125 | 123 | 6.85 | 130 | 18 | 1 | 2.95 | 2.95 | 2.95 | 14.8 | 384.3 | 29.18 | 0.2304 |
| 125 | 120 | 19.6 | 140 | 26 | 7 | 2.43 | 1.89 | 5.67 | 15.4 | 460.8 | 44.49 | 0.2308 |
| 160 | 158 | 8.77 | 167 | 18 | 1 | 3.34 | 3.34 | 3.34 | 16.7 | 491.9 | 36.38 | 0.18 |
| 160 | 154 | 25 | 179 | 26 | 7 | 2.74 | 2.13 | 6.39 | 17.4 | 589.8 | 56.18 | 0.1803 |
| 200 | 197 | 10.96 | 208 | 18 | 1 | 3.74 | 3.74 | 3.74 | 18.7 | 614.9 | 43.62 | 0.144 |
| 200 | 192 | 31.3 | 223 | 26 | 7 | 3.07 | 2.39 | 7.16 | 19.4 | 737.2 | 69.27 | 0.1443 |
| 250 | 244 | 24 | 268 | 22 | 7 | 3.76 | 2.09 | 6.27 | 21.3 | 830.9 | 67.8 | 0.1153 |
| 250 | 240 | 39.1 | 279 | 26 | 7 | 3.43 | 2.67 | 8.01 | 21.7 | 921.5 | 86.58 | 0.1154 |
| 315 | 310 | 21.4 | 331 | 45 | 7 | 2.96 | 1.97 | 5.91 | 23.7 | 996.4 | 8.33 | 0.0917 |
| 315 | 303 | 49.3 | 352 | 26 | 7 | 3.85 | 2.99 | 8.97 | 24.4 | 1161.1 | 107.58 | 0.0916 |
| 400 | 393 | 27.2 | 420 | 45 | 7 | 3.34 | 2.22 | 6.66 | 26.7 | 1265.3 | 97.5 | 0.0722 |
| 400 | 387 | 50.2 | 437 | 54 | 7 | 3.02 | 3.02 | 9.06 | 27.2 | 1402.9 | 124.2 | 0.0723 |
| 450 | 442 | 30.6 | 473 | 45 | 7 | 3.54 | 2.36 | 7.08 | 28.3 | 1423.4 | 107.48 | 0.0642 |
| 450 | 436 | 56.5 | 493 | 54 | 7 | 3.21 | 3.21 | 9.63 | 28.9 | 1578.2 | 139.72 | 0.0642 |
| 500 | 492 | 34 | 526 | 45 | 77 | 3.73 | 2.49 | 7.47 | 29.8 | 1581.6 | 119.42 | 0.0578 |
| 500 | 484 | 62.8 | 547 | 54 | 7 | 3.38 | 3.38 | 10.14 | 30.4 | 1753.6 | 153.99 | 0.0578 |
| 560 | 550 | 38.1 | 588 | 45 | 7 | 3.95 | 2.63 | 7.89 | 31.6 | 1771.4 | 133.75 | 0.0516 |
| 560 | 543 | 68.8 | 612 | 54 | 19 | 3.58 | 2.15 | 10.75 | 32.2 | 1956.3 | 169.36 | 0.0516 |
| 630 | 619 | 42.8 | 662 | 45 | 7 | 4.19 | 2.79 | 8.37 | 33.5 | 1992.8 | 150.47 | 0.0458 |
| 630 | 611 | 77.3 | 688 | 54 | 19 | 3.79 | 2.28 | 11.4 | 34.2 | 2200.9 | 190.52 | 0.0459 |
| 710 | 687 | 48.3 | 746 | 45 | 7 | 4.44 | 2.96 | 8.88 | 35.6 | 2245.8 | 169.57 | 0.0407 |
| 710 | 688 | 87.2 | 775 | 54 | 19 | 4.03 | 2.42 | 12.1 | 36.3 | 2480.3 | 214.72 | 0.0407 |
| 800 | 791 | 34.2 | 825 | 72 | 7 | 3.74 | 2.49 | 7.47 | 37.4 | 2412.8 | 167.67 | 0.0361 |
| 800 | 784 | 65.3 | 849 | 84 | 7 | 3.45 | 3.45 | 10.35 | 37.9 | 2598.9 | 206.37 | 0.0362 |
| 800 | 775 | 98.2 | 873 | 54 | 19 | 4.28 | 2.57 | 12.85 | 38.5 | 2794.7 | 241.94 | 0.0361 |
| 900 | 890 | 38.5 | 929 | 72 | 7 | 3.97 | 2.65 | 7.95 | 39.7 | 2714.4 | 188.63 | 0.0321 |
| 900 | 862 | 73.5 | 936 | 84 | 7 | 3.66 | 3.66 | 10.98 | 40.2 | 2923.8 | 224.82 | 0.0321 |
| 1000 | 989 | 42.7 | 1032 | 72 | 7 | 4.18 | 2.79 | 8.37 | 41.8 | 3016 | 209.59 | 0.0289 |
| 1120 | 1108 | 46.8 | 1155 | 72 | 19 | 4.43 | 1.77 | 8.85 | 44.3 | 3372.6 | 233.48 | 0.0258 |
| 1120 | 1098 | 89.4 | 1187 | 84 | 19 | 4.08 | 2.45 | 12.25 | 44.9 | 3628.4 | 282.88 | 0.0258 |
| 1250 | 1237 | 52.2 | 1289 | 72 | 19 | 4.68 | 1.87 | 9.35 | 46.8 | 3764.1 | 260.58 | 0.0231 |
| 1250 | 1225 | 99.8 | 1325 | 84 | 19 | 4.31 | 2.59 | 12.95 | 47.4 | 4049.5 | 315.72 | 0.0231 |
| Code | Area | Number of Wires | Wire Diameter | Conductor Diameter | Linear Mass | Rated Strength | ||
| Al | ACS | Al | ACS | |||||
| \ | AWG or MCM | Nos | Nos | mm | mm | mm | kg/km | kN |
| Swan\AW | 4 | 6 | 1 | 2.12 | 2.12 | 6.36 | 81 | 7.9 |
| Swante\AW | 4 | 7 | 1 | 1.96 | 2.61 | 6.53 | 93 | 10.1 |
| Swallow\AW | 2 | 6 | 1 | 2.38 | 2.38 | 7.14 | 103 | 9.9 |
| Sparrow\AW | 2 | 6 | 1 | 2.67 | 2.67 | 8.01 | 128 | 12.3 |
| Sparate\AW | 2 | 7 | 1 | 2.47 | 3.30 | 8.24 | 149 | 15.6 |
| Robin\AW | 1 | 6 | 1 | 3.00 | 3.00 | 9.00 | 162 | 15.3 |
| Raven\AW | 0 | 6 | 1 | 3.37 | 3.37 | 10.11 | 205 | 18.9 |
| Quail\AW | 2/0 | 6 | 1 | 3.78 | 3.78 | 11.34 | 259 | 22.8 |
| Pigeon\AW | 3/0 | 6 | 1 | 4.25 | 4.25 | 12.75 | 326 | 28.0 |
| Penguin\AW | 4/0 | 6 | 1 | 4.77 | 4.77 | 14.31 | 412 | 34.2 |
| Waxwing\AW | 266.8 | 18 | 1 | 3.09 | 3.09 | 15.45 | 421 | 30.3 |
| Partridge\AW | 266.8 | 26 | 7 | 2.57 | 2.00 | 16.28 | 519 | 48.0 |
| Ostrich\AW | 300.0 | 26 | 7 | 2.73 | 2.12 | 17.28 | 583 | 53.8 |
| Merlin\AW | 336.4 | 18 | 1 | 3.47 | 3.47 | 17.35 | 531 | 38.0 |
| Linnet\AW | 336.4 | 26 | 7 | 2.89 | 2.25 | 18.31 | 655 | 60.0 |
| Oriole\AW | 336.4 | 30 | 7 | 2.69 | 2.69 | 18.83 | 737 | 74.3 |
| Chickadee\AW | 397.5 | 18 | 1 | 3.77 | 3.77 | 18.85 | 628 | 43.5 |
| Brant\AW | 397.5 | 24 | 7 | 3.27 | 2.18 | 19.61 | 731 | 62.7 |
| Lbis\AW | 397.5 | 26 | 7 | 3.14 | 2.44 | 19.88 | 774 | 70.3 |
| Lark\AW | 397.5 | 30 | 7 | 2.92 | 2.92 | 20.44 | 869 | 87.2 |
| Pelican\AW | 477.0 | 18 | 1 | 4.12 | 4.14 | 20.70 | 755 | 51.2 |
| Flicker\AW | 477.0 | 24 | 7 | 3.58 | 2.39 | 21.49 | 877 | 74.3 |
| Hawk\AW | 477.0 | 26 | 7 | 3.44 | 2.67 | 21.79 | 929 | 84.1 |
| Hen\AW | 477.0 | 30 | 7 | 3.20 | 3.20 | 22.40 | 1043 | 104.1 |
| Osprey\AW | 556.5 | 18 | 1 | 4.47 | 4.47 | 22.35 | 880 | 58.7 |
| Parakeet\AW | 556.5 | 24 | 7 | 3.87 | 2.58 | 23.22 | 1022 | 85.8 |
| Dove\AW | 556.5 | 26 | 7 | 3.72 | 2.89 | 23.55 | 1083 | 97.4 |
| Eagle\AW | 556.5 | 30 | 7 | 3.46 | 3.46 | 24.21 | 1217 | 119.2 |
| Peacock\AW | 605.0 | 24 | 7 | 4.03 | 2.69 | 24.20 | 1112 | 93.4 |
| Squab\AW | 605.0 | 26 | 7 | 3.87 | 3.01 | 24.51 | 1117 | 105.0 |
| Wood duck\AW | 605.0 | 30 | 7 | 3.61 | 3.61 | 25.25 | 1323 | 126.3 |
| Teal\AW | 605.0 | 30 | 19 | 3.61 | 2.16 | 25.24 | 1314 | 126.8 |
| Kingbird\AW | 636.0 | 18 | 1 | 4.78 | 4.78 | 23.88 | 1006 | 66.7 |
| Swift\AW | 636.0 | 36 | 1 | 3.38 | 3.38 | 23.62 | 946 | 60.5 |
| Rook\AW | 636.0 | 24 | 7 | 4.14 | 2.76 | 24.84 | 1168 | 97.9 |
| Grosbeak\AW | 636.0 | 26 | 7 | 3.97 | 3.09 | 25.15 | 1238 | 110.3 |
| Sooter\AW | 636.0 | 30 | 7 | 3.70 | 3.70 | 25.88 | 1391 | 130.3 |
| Egret\AW | 636.0 | 30 | 19 | 3.70 | 2.22 | 25.90 | 1381 | 133.0 |
| Flamingo\AW | 666.6 | 24 | 7 | 4.23 | 2.82 | 25.40 | 1225 | 102.7 |
| Gannet\AW | 666.6 | 26 | 7 | 4.07 | 3.16 | 25.76 | 1298 | 115.6 |
| Stilt\AW | 715.5 | 24 | 7 | 4.39 | 2.92 | 26.31 | 1314 | 110.3 |
| Starling\AW | 715.5 | 26 | 7 | 4.21 | 3.28 | 26.68 | 1393 | 122.3 |
| Redwing\AW | 715.5 | 30 | 19 | 3.92 | 2.35 | 27.43 | 1552 | 148.6 |
| Coot\AW | 795.0 | 36 | 1 | 3.77 | 3.77 | 26.41 | 1183 | 73.8 |
| Cuckoo\AW | 795.0 | 24 | 7 | 4.62 | 3.08 | 27.74 | 1460 | 122.3 |
| Drake\AW | 795.0 | 26 | 7 | 4.44 | 3.45 | 28.11 | 1549 | 135.7 |
| Tern\AW | 795.0 | 45 | 7 | 3.38 | 2.25 | 27.03 | 1298 | 95.6 |
| Condor\AW | 795.0 | 54 | 7 | 3.08 | 3.08 | 27.72 | 1458 | 123.7 |
| Mallard\AW | 795.0 | 30 | 19 | 4.14 | 2.48 | 28.96 | 1726 | 165 |
| Ruddy\AW | 900.0 | 45 | 7 | 3.59 | 2.40 | 28.73 | 1470 | 106.8 |
| Canary\AW | 900.0 | 54 | 7 | 3.28 | 3.28 | 29.52 | 1653 | 137.9 |
| Catbird\AW | 954.0 | 36 | 1 | 4.14 | 4.14 | 28.95 | 1420 | 86.7 |
| Rail\AW | 954.0 | 45 | 7 | 3.70 | 2.47 | 29.61 | 1558 | 113 |
| Cardinal\AW | 954.0 | 54 | 7 | 3.38 | 3.38 | 30.42 | 1752 | 146.3 |
| Tanager\AW | 1033.5 | 36 | 1 | 4.30 | 4.30 | 30.12 | 1537 | 93.9 |
| Ortolan\AW | 1033.5 | 45 | 7 | 3.85 | 2.57 | 30.81 | 1688 | 120.5 |
| Curlew\AW | 1033.5 | 54 | 7 | 3.52 | 3.52 | 31.68 | 1896 | 158.3 |
| Bluejay\AW | 1113.0 | 45 | 7 | 4.00 | 2.66 | 31.98 | 1819 | 130.3 |
| Finch\AW | 1113.0 | 54 | 19 | 3.65 | 2.19 | 32.85 | 2043 | 166.8 |
| Bunting\AW | 1192.5 | 48 | 7 | 4.14 | 2.76 | 33.12 | 1948 | 139.2 |
| Grackle\AW | 1192.5 | 54 | 19 | 3.77 | 2.27 | 33.97 | 2188 | 178.8 |
| Skylark\AW | 1272.0 | 36 | 1 | 4.78 | 4.78 | 33.42 | 1893 | 114.3 |
| Bittern\AW | 1272.0 | 45 | 7 | 4.27 | 2.85 | 34.17 | 2078 | 148.6 |
| Pheasant\AW | 1272.0 | 54 | 19 | 3.90 | 2.34 | 35.10 | 2333 | 188.6 |
| Dipper\AW | 1351.5 | 45 | 7 | 4.40 | 2.92 | 35.16 | 2207 | 157.9 |
| Martin\AW | 1351.5 | 54 | 19 | 4.02 | 2.41 | 36.17 | 2478 | 200.6 |
| Bobolink\AW | 1431.0 | 45 | 7 | 4.53 | 3.02 | 36.24 | 2336 | 167.2 |
| Plover\AW | 1431.0 | 54 | 19 | 4.14 | 2.48 | 37.24 | 2625 | 212.2 |
| Nuthatch\AW | 1510.5 | 45 | 7 | 4.65 | 3.10 | 37.20 | 2467 | 176.8 |
| Parrot\AW | 1510.5 | 54 | 19 | 4.25 | 2.55 | 38.25 | 2768 | 223.7 |
| Lapwing\AW | 1590.0 | 45 | 7 | 4.77 | 3.18 | 38.16 | 2598 | 185.9 |
| Falcon\AW | 1590.0 | 54 | 19 | 4.36 | 2.62 | 39.26 | 2917 | 235.7 |
| Chukar\AW | 1780.0 | 84 | 19 | 3.70 | 2.22 | 40.70 | 2996 | 219.7 |
| BlueBird\AW | 2156.0 | 84 | 19 | 4.07 | 2.44 | 44.76 | 3627 | 262.4 |
| Kiwi\AW | 2167.0 | 72 | 7 | 4.41 | 2.94 | 44.07 | 3366 | 218.4 |
| Thrasher\AW | 2312.0 | 76 | 19 | 4.43 | 2.09 | 45.90 | 3679 | 246 |
